TO RESTART A WARM ENGINE
Do NOT push choke button in.
a. Turn switch to “I” ON position.
b. Ensure primer bulb has fuel inside.
c. Rapidly pull starter/grip until engine starts.
d. Squeeze throttle to provide fuel to engine and use for
intended task.
TO STOP THE ENGINE
To stop the engine, depress the STOP switch to the
“STOP”position.
OPERATING THE TRIMMER
WARNING.
Engine housing can become hot during
trimmer operation. Do not rest or place your arm, hand,
or any body part against the engine housing during
trimmer operation. Only hold the trimmer with all body
parts clear of engine housing. Extended contact with the
engine housing can result in burns or other injuries.
Always position the unit on the operator’s right side. The use of
the unit on the operator’s left side will expose the user to hot
surfaces and can result in possible burn injury.
To avoid burns from hot surfaces, never operate unit with the
bottom of the engine above waist level.
STARTING/STOPPING THE CUTTING HEAD
SPOOL (FIG. 10)
The cutting head spool will be engaged if the operator squeezes
the throttle lever and then squeezes the throttle lever release to
increase the engine speed.
The engine will stop when depressing the switch in “STOP”
position.
Note: This ignition switch will come back to ON position
automatically.
WORKING WITH THE TRIMMER
1. Hold the trimmer with your right hand on the rear handle
and your left hand on the front handle. Keep a firm grip
with both hands while in operation. Trimmer should be held
at a comfortable position with the rear handle about hip
height, Fig.11.
2. Keep your body and feet in safety distance to cutting head.
3. Squeezing the throttle lever to full speed before cutting.
4. The cutting line should run parallel to the ground surface.
TO ADJUST THE TRIMMING LINE LENGTH
The line spool has bump feed function. The line will be extended
by tapping the spool head shortly and lightly onto the ground
while the unit is running at high speed.
1. Run engine at high speed.
2. Tap the spool head on bare ground to release line.
3. A blade in the cutting head shield will cut the line to the
proper length if any excess line is released.
NOTE: Do not hold the spool head on the ground while the unit
is running.
The line releases each time the spool head is tapped.
Always keep the trimming line fully extended. Line release
becomes more difficult when the cutting line gets shorter.
OPERATION
Fig. 10
Fig. 11
Ignition switch Throttle lever
Throttle lever release
