17
MAINTENANCE
REPLACING THE CUTTING LINE SPOOL
1. Open the cutting line spool by pressing two release buttons
on the side and take out the winding core (Fig.14 & 15).
2. Divide a spare cutting line in 2 equal halves, fix it in the
winding core and start to wind the cutting line in two
separated rails (Fig.15). Please follow the indicated
winding.
3. Fix the 2 line ends (approx. 15cm) at the opening to keep
the line wound tightly. (Fig.16)
4. Guide the 2 line ends into the holes on the spool housing
and restore the spool cover. (Fig.17)
Fig. 17
Fig. 14
Fig. 16
Fig. 15
