Stannah 600 - Certificate of Test and Examination after Installation; Description; Electrical Tests; Battery Checks

Certificate of Test and Examination after Installation of 600 Model Stairlift to ensure Compliance with
CE Directives:
Machinery Directive (2006/42/EC) Low Voltage Directive (2006/95/EC), EMC Directive (2004/108/EC)
Name and Address of User / Installation site: ………………………………………………………. Tel: …………………..
1. Description
a) Manufacturer: Stannah Stairlifts Ltd
b) Stairlift reference number:……………………………..Chair batch No. ………………………………. Carriage batch No.…………………………
c) Safe Working Load
24 to 52 degrees = 160kg (352lbs)
Siena / Starla Manual and Powered Swivel
24 to 52 degrees = 135kg (297lbs)
Sofia / Solus Manual and Powered Swivel
d) Rated speed: 0.1m/s g) Model type: 600
e) Motor tested on assembly: YES h) Type of motor: DC
f) Control actuator type: Constant pressure controls i) Motor protection (type): Electronic
j) Type of drive: Rack and pinion
2.
Electrical Tests
3. Battery Checks
a) Battery charge voltage:
V DC d) Confirm batteries are fully charged: YES / NO
b) Confirm battery enclosure is vented: YES / NO
e) Confirm no leak when battery is fitted:
YES / NO
c) Confirm batteries are securely fitted: YES / NO f) Confirm off charge indicator is functional: YES / NO
4. Mechanical / Operation Test
5. Confirmation
Confirm operating instructions have been handed to the user and the user has been instructed on use of stairlift: YES / NO
6. Declaration
We certify that on (DATE) ……………………………………… this stairlift was thoroughly examined and found to be free from obvious defects
and that the foregoing is a correct report of the results.
Signed: ……………………………………………………… Position / Qualifications: ………………………………………………
GB
SWITCH OPERATION
a) Confirm all on / off stop switches operate correctly: YES / NO
b) Confirm all control limits operate correctly: YES / NO
c) Confirm final limits operate correctly: YES / NO
d) Confirm all sensitive edges / surfaces operate correctly: YES / NO
e) Confirm underside sensitive surfaces operate correctly and to the appropriate direction of travel YES / NO
f) Tests to verify the function of the Overspeed Governor and Safety Gear YES / NO
g) Confirm that all interlock switches operate correctly (e.g on rotating seat, chair arm isolation etc) YES / NO
h) Confirm retractable rail safety pad switch stops carriage in down direction YES / NO
j) Confirm that retractable rail clutch slips when manually raised YES / NO
COMPONENT FUNCTIONING
k) State the stopping distance of the carriage with rated load upon application of the brake: Up..….......mm Down......…mm
l) Confirm hand winding controls operate correctly. YES / NO
m) Confirm Over speed Governor has been subjected to factory test for correct tripping speed: YES / NO
n) Confirm Installation Overload test has been carried out YES / NO
o) If an alarm is fitted, confirm mode of operation and that the system operates correctly: YES / NO
p) Confirm clearance of at least 100mm between chair arms and any part of fixed installation whilst in travel position. YES / NO
q) Ensure minimum 500mm between adjacent stairlifts during full length of travel YES / NO
r) Confirm that main entrance and exit doors are not obstructed when stairlift not in use YES / NO
s) Confirm clearance of 1000mm between seat centre and any height restriction during full length of travel YES / NO
t) Confirm required hazard warning labels are fitted YES / NO
u) State distance of footrest above floor level: Not to exceed 170mm Upper………… mm Lower ………… mm
v) State distance of seat above floor level: Not to exceed 650mm Upper ………… mm Lower ………… mm
i) Confirm that retractable rail safety arm prevents carriage from clashing with the retractable rail. YES / NO
a) Electrical supply voltage at time of test: …………V AC g) Polarity check: L-N = ………. L-E = ………. N-E = ……….
b) Battery voltage: …………V DC h) 0-volt rail connected and continuity tested: YES / NO
c) Functional overload protection test: YES / NO i) Confirm battery polarity check: + ve …. - ve ….
d) Tripping time: ……… Seconds j) AC supply frequency: …………Hz
e) Control voltage: 24V DC k) Phase: Single
f) Mains fuse rating: ………… Amps l) Motor reversal delay: ………… Seconds
