FT5X User Guide
Caution: FT5X does NOT support switch among GSM voice/Fax. This
function requires GSM network supporting TS61 (allowing user to use voice
and fax functions in one call). As a result, when sending a fax, please press
START key immediately after you complete dialing numbers; When receiving
faxes, please set fax machine to auto-receiving fax mode.
4.3 Data Function
4.3.1 POS function
When the traditional POS connected to the FT5X, through the RJ11 ports (phone port
and fax port) you should make sure the number the traditional POS dialed out is data
number.
1. the number dialed out is data number, use the traditional POS as usual.
2. when you are not sure the dialing number through the traditional POS whether it is
the data number. Just add the prefix *02* before the dialed number to ensure the call is
data call.
4.3.2 Modem function
The FT5X has two work modes：Common Mode and Modem Mode. These two modes
cannot exist simultaneity.
Common Mode：The wireless access terminal can provide all the function except the
GPRS under the Common Mode.
Modem Mode：The data service provided through the serial port of the wireless
Voice/Data/Fax access terminal by using peripheral equipments in order to provide the
GPRS application.
Establishing the Modem Mode：
1. When the auto-switch mode configured by the user (refer to the below the
keyboard setup command), the PC serial port needs to be connected to the IOIO port in
the wireless access terminal. Open the serial port in PC, and then the device will be auto-
switched to the Modem mode.
2. Under the Modem Mode, the user can control the GSM/GPRS mode through the
serial port directly. And user can apply the software in PC to realize the GPRS, DATA, FAX,
SMS function on the GSM.
3. Using the device under the Modem Mode
a) Under the auto-switch mode（Set #*83*1# ），when there is the incoming call
on the GSM, the user can configure the mode as “Switch the mode while ringing” or “
Switch after picking up the phone”.
b) Under the restricted Modem mode (Set #*83*2# )， the device wont be
switched to the Common Mode when calls income.
Note
：
Above keyboard configuration commands are setup with the common
phone. Please refer to “4.4 keyboard configuration command” for the detailed
configuration.
12/31
