11 ELECTRICAL PARTS LIST
Part No
Diag No
Description
E010001
E010036
SW1
On/Off Switch
Rocker Switch Cover IP65 (Stainless Steel model)
E017003
F2
Mains Fuse
E017008
F1
Solenoid Fuse
E003008
R1
Weld Relay
E022002
D1
Rectifier Diode
E021003
S
Supressor
E010005
E010006
SW2
Standard Foot Switch
Heavy Duty Foot Switch (Stainless Steel Model)
E011011
RS1
Safety Micro Switch
E005001
E005028
TH126
MKVI Controller
MKVI (C) Controller (MKVI C Model)
B014002
Membrane Keypad
E001001
TR1
Transformer
E002001
E002002
E002005
SOL
Solenoid Complete
Cone Solenoid Complete
Solenoid Plunger
E011014
SW3
Vacuum Pump Switch
P201001
VP
Vacuum Pump
E013005
E013006
SKT
3 Pin Socket
3 Pin Plug
B022001
Probe Roller Bush
B021004
Clamp Jaw Return Spring Right
B021008
Clamp Jaw Return Spring Left
P203006
Vacuum Regulator
P202001
Vacuum Gauge
M105008
Vacuum Probe
E019006
TC
Thermocouple (MKVI C Model)
E013016
Mains Lead & Plug
B021006
Solenoid Return Spring
M202007
Solenoid Pin
M102008
Brass Link
B016001
Jaw Arm Gaiter (Pair) (If IP rated)
ALL PARTS QUOTED IN THIS MANUAL ARE CORRECT
AT THE TIME OF PUBLICATION E&OE
STAR UNIVERSAL RESERVE THE RIGHT TO REVIEW
AND ALTER THE PARTS AS NECESSARY
COMPONENTS AND LAYOUT MAY VARY FROM THOSE PICTURED
