7 A5-RG3009 1 DRAWER FRONT ASSY 30BB,45ABB
A5-RG5004 1 DRAWER FRONT ASSY 50BB,75ABB
8 2D-Z5898 1 BUN PAN 2/3 4” 30BB,45ABB
2D-Z5899 1 BUN PAN FULL 4” 50BB,75ABB
9 A5-Z2169 2 SIDE PANEL 20,30,50
A5-Z2265 2 SIDE PANEL 45A,75A
A5-Z5347 2 SIDE PANEL 75AF,45AF
A5-Z5401 2 SIDE PANEL 30F,50F
10 A5-Z6719 1 CHAIN GUIDE 20,30,50
A5-Z2260 1 CHAIN GUIDE 45A,75A
A5-Z6615 1 CHAIN GUIDE 75AF,45AF
A5-Z5398 1 CHAIN GUIDE 30F,50F
11 A5-Z8409 & 8410 1 CHAIN RETAINER 20,30,50
A5-Z8411 & 8412 1 CHAIN RETAINER 45A,75A
12 A5-Z2171 2 ELEMENT SUPPORT 20,30,50
A5-Z2262 2 ELEMENT SUPPORT 45A,75A
13 2P-Z2174 22/32 TUBE GUIDE 20,30D,30,45A,50,75A
14 2I-Z2175 22/32 ORING SEAL 20,30D,30,45A,50,75A
2I-Z2175 33/48 ORING SEAL 30DV,45ADV,50DV,75ADV
15 2P-Z8392 1 IDLER ASSY RG 20,30D,30,45A,50,75A
16 2A-Z8017 1 IDLER BUSHING RG 20,30D,30,45A,50,75A
17 2P-Z8317 1 MOTOR SPROCKET 3/8 BORE 20,30D,30,45A,50,75A
18 2N-Z2178 11/16 ELEMENT 100W 120V 30,45A
2N-Z2179 11/16 ELEMENT 135W 120V 50
2N-Z2181 11/16 ELEMENT 80W 120V 20,30D
2N-Z2193 11/16 ELEMENT 135 W 230V 50,75A
2N-Z2194 11/16 ELEMENT 100 W 230V 30,45A
2N-Z2611 11/16 ELEMENT 80W 115V CE 20,30D
2N-Z2982 16 ELEMENT 110W 75A
2N-Z6441 16 ELEMENT 177W 120 VOLT 75AFV
19 PS-RG5069 1 MOTOR-120 VOLT 20,30D,30,45A,50,75A
PS-RG5070 1 MOTOR-230 VOLT 20,30D,30,45A,50,75A
20 2J-Z2195 2 CONTROL 120 VOLT 20,30D,30,45A,50,75A
2J-Z2192 2 CONTROL 240 VOLT 2 0,30D,30,45A,50,75A
N/A A5-RG4512 2/4 WIRE ASSY LONG 20,30D,30,45A,50,75/75AFV
N/A A5-RG4513 1 WIRE ASSY LONG-CE 20,30D,30,45A,50,75A
21 2E-Z1858 1 SWITCH DPST-RED 20,30D,30,45A,50,75A
2E-Z3156 1 SWITCH DPST-YELLOW 20,30D,30,45A,50,75A (230V ONLY)
2E-Z6443 1 SWITCH DPST-BLACK 75AFV
22 2R-Z1854 2 KNOB w/SET SCREW 20,30D,30,45A,50,75A
23 PS-RG2029 11/16 ROLLER ASSEMBLY CHROME 20,30D
PS-RG2030 11/16 ROLLER ASSEMBLY POLY 20S,30DS
PS-RG3077 11/16 ROLLER ASSEMBLY CHROME 30,45A
PS-RG3078 11/16 ROLLER ASSEMBLY POLY 30S,45AS
PS-RG7562 11/16 ROLLER ASSEMBLY CHROME 50,75A,75AFV
PS-RG7563 11/16 ROLLER ASSEMBLY POLY 50S,75SA
N/A 2M-Z2377 1 DRAWER LABEL 30/45A 30BB,45ABB
N/A 2M-Z2380 1 DRAWER LABEL 50/75A 50BB,75ABB
24 2P-Z2242 1 CHAIN 20,30,50
2P-Z2266 1 CHAIN 30D,45A,75A
2P-Z5336 1 CHAIN 75AF,45AF,75AFV
2P-Z5384 1 CHAIN 30F,50F
N/A A5-RG2006 1 WIRE ASSY #5 20,30D,30,45A,50,75A
N/A A5-RG2007 1 WIRE ASSY #6 20,30D,30,45A,50,75A
25
28 2R-Z5846 4 FOOT ALL EXCEPT 75A
2R-Y5092 4 FOOT 4” ADJUSTABLE 75A
29 2J-Z3157 3 PILOT LIGHT-YELLOW 20,30D,30,45A,50,75A (230V ONLY)
PARTS LIST November 16, 2010
Star Manufacturing International, Inc.
MODEL
Grill-Max Roller Grills
Series 20, 30, 45A, 50 and 75A
Number
Per
Unit
Description & Model Designation
Part
Number
Key
Number
