2J-Z2329 3 PILOT LIGHT-RED 20,30D,30,45A,50,75A
30 C3-G8021 1/2 CORD ASSY 120V 20,30D,30,45A,50,75A,75SAF/75AFV
C3-G8022 1 CORD ASSY 240V 75A
31 2E-Z0512 1 CORD 230V 20,30D,30,45A,50
2E-Y9251 1 CORD 230V 75A
32 2E-Y9227 1 CORD INLET 230V 20,30D,30,45A,50
2E-Y9253 1 CORD INLET 230V 75A
33 2K-Y3240 1 CORD BUSHING 20,30D,30,45A,50,75A
34 2P-Z0315 4 DRAWER ROLLER w/SCREW 30BB,45ABB,50BB,75ABB
35 2K-Y1139 3 BUSHING ANTI-SHORT 20,30D,30,45A,50,75A
N/A 2P-6475 3 WIRE TIE 20,30D,30,45A,50,75A
N/A 2P-Z0584 1 TONGS 20,30D,30,45A,50,75A
36 2P-Z1540 2 PLUG-HOLE 20,30D,30,45A,50,75A
37 1P-E1524 -- INSULATING TAPE 20,30D,30,45A,50,75A
38 2P-Z5098 11/16 GREASE SEAL 30DV,45ADV,50DV,75ADV
39 A5-Z5158 1 GRILL DIVIDER 30DV,50DV
39 A5-Z5157 1 GRILL DIVIDER 45ADV,75ADV
40 A5-RG3037 1 DOOR-FRONT-20.125 30SBBC
A5-RG5016 1 DOOR-FRONT-32.125 50SBBC
41 2A-Z4332 1 SCREW, SHOULDER, #6-32UNC 30SBBC,50SBBC
42 2A-Z4333 1 PIN-RETAINER 30SBBC,50SBBC
43 2P-Z4337 1 SPRING-COMPRESSION 30SBBC,50SBBC
44 2A-Z4667 1 SHAFT 30SBBC,50SBBC
45 A5-Z4660 1 BRACKET-DOOR 30SBBC,50SBBC
46 A5-Z4657 1 ARM-DOOR 30SBBC,50SBBC
47 A5-Z4661 1 BRACKET-SPRING MOUNT 30SBBC,50SBBC
48 2C-Z4680 1 RING, RETAINER 30SBBC,50SBBC
49 2P-Z4683 1 SPRING-EXTENSION 30SBBC,50SBBC
N/A 2E-Z2395 1 WIRE SET 20,30D,30,45A,50,75A
N/A A5-RG2012 1 WIRE SET 20 230V
N/A A5-RG3018 1 WIRE SET 30D 230V ONLY
N/A 2E-Z6442 1 WIRE SET 75AFV
50 A5-RG7516 1 ASSY - CONTROL COVER DOOR 75SAF-SA
51 2P-Y9176 2 SNAP BUTTON 75SAF-SA
52 2P-Z6455 22/32 TUBE SEAL, SOLID 50BB,50S,75ABB,75SA
N/A PS-Z3018 TUBE ASSEMBLY SLEEVE (not shown)
PARTS LIST November 16, 2010
Star Manufacturing International, Inc.
MODEL
Grill-Max Roller Grills
Series 20, 30, 45A, 50 and 75A
Number
Per
Unit
Description & Model Designation
Part
Number
Key
Number
