Star 4 QUART User Manual

10
Model: 4RW, 7RW, 11RW, 4RW-P, 11RW-P Round
Warmers
Fig No. Part No. Qty Description Application
28 N2-Y4146 1 WASHER 4RW, 11RW
29 2I-Y9636 1 ROD-PLUNGER 4RW, 11RW
30 2I-Y4143 1 O-RING 4RW, 11RW
31 2P-Y6196 2 BALL-VALVE 4RW, 11RW
32 2A-Y7658 1 NUT 4RW, 11RW
33 2I-Z0730 1 PUMP-CHAMBER 4RW, 11RW
34 2A-Y9685 1 PIN “U” 4RW, 11RW
35
2V-62008
1 DISPENSE TUBE ASSY
4RW-P
2V-62006 11RW-P
36 2P-Y6211 1 BRUSH 4RW, 11RW
37 2T-Z0622 1 THERMOSTAT, HIGH LIMIT 7RW, 11RW
39
N2-30455
1 SPACER
4RW
N2-Y8926 4RW-P
40 2R-Z0872 1 KNOB 4RW-L
41 2L-Z0541 1 COVER 4RW-L
42 2C-T1004 1 SCREW 4RW-L
43 2L-Z0540 1 RING 4RW-L
44 2L-Z0577 1 LADLE , 1 OZ. 4RW-L
45 2R-Y5701 1 HANDLE-INSULATING 4RW-4H, 7RW-7H, 11RW-11H
46
01-RW0003
1
HINGED LID ASSEMBLY 7RW-7H
01-RW0005 HINGED LID ASSEMBLY 11RW-11H
N2-30436 HINGED LID ASSEMBLY 4RW-4H
47 02-Y5703 1 HINGE LEAF 4RW-4H, 7RW-7H, 11RW-11H
48 2B-Y5792 2 HINGE PIN 4RW-4H, 7RW-7H, 11RW-11H
49
01-RW0002
1 HINGED BOWL ASSEMBLY
7RW-7H
01-RW0004 11RW-11H
N2-30437 4RW-4H
51
2L-Y8876
1
COVER 4 QT FORMED 4RW, 4RW-L (OPTIONAL)
2L-Y6594 COVER 7 QT FORMED 7RW (OPTIONAL)
2L-Y6596 COVER 11 QT FORMED 11RW (OPTIONAL)
52
2D-Y8877
1
BOWL 4 QT
4RW, 4RW-L (OPTIONAL)
4RW-4H (INCLUDED)
2D-H5868 BOWL 7 QT 7RW (OPTIONAL)
2D-Y3464 BOWL 11 QT 11RW (OPTIONAL)
53 2D-H6295 1 INSET 4RW-L, 4RW-P (OPTIONAL)
54 N2-30404 1 PUMP - COMPLETE 4RW-P
55 N2-61007 1 PUMP - COMPLETE 11RW
