Model: 4RW, 7RW, 11RW, 4RW-P, 11RW-P Round Warmers
Fig No. Part No. Qty Description Application
1
O1-30323
1
CORD ASSY 120V 4RW
O1-30324 CORD ASSY 120V 7RW
O1-30325 CORD ASSY 120V 11RW
O1-30326 CORD ASSY 120V CSA 11RW
O1-30332 CORD ASSY 240V
2 2C-2560 5 NUT 10-24
3 2C-Y5059 4 POP RIVET
4 2I-Z0057 4 FOOT
5
O1-Y9901
1 BOTTOM
4RW
O1-Y9900 7RW
O1-Y9899 11RW
6
2K-7889
1 BUSHING 90° HEYCO
4RW, 7RW
2K-Y3240 11RW
7 2R-Y8261 1 KNOB-THERMOSTAT
8 2C-1628 3 SCREW #4 x 1/4
9
O1-Y9895
1 OUTER SHELL
4RW
O1-Y9894 7RW
O1-Y9828 11RW
10
N2-Y8130
1 BAND-ELEMENT
4RW
O1-Z0437 7RW
O1-Y9787 11RW
11 N2-Y8310 1 PLATE 11RW
12 2C-H5569 3 POP RIVET 1/8 x .7
13
2N-Z0384
1
ELEMENT 120V, 600W 4RW
2N-Z0385 ELEMENT 120V, 1100W 7RW
2N-Z0205 ELEMENT 120V, 1600W 11RW
2N-Z0708 ELEMENT, 240V, 600W 4RW
2N-Z0664 ELEMENT, 240V, 1100W 7RW
2N-Z0665 ELEMENT, 240V, 1600W 11RW
14
2C-1496
1
SCREW 8-32 x 3/4 4RW
2C-2807 SCREW 8-32 x 1 3/8 7RW, 11RW
15 2C-H8670 1 WASHER-LOCK #8
16 2C-2556 1 NUT #8-32
17 2T-Z0245 1 THERMOSTAT
18
O1-Z0230
1 BRACKET-THERMOSTAT
4RW
O1-Z0440 7RW, 11RW
19
N2-Y8127
1 BAND-HEATER
4RW
O1-Z0436 7RW
O1-Y9786 11RW
20 2V-Z0297 3 SPACER
21
O1-30314
1 HEATWELL ASSY
4RW
O1-30328 7RW
O1-30316 11RW
22 2R-Y9854 1 KNOB-BLK 4RW, 11RW
23 2A-Y9637 1 NUT 4RW, 11RW
24
2L-Y7618
1
COVER 4RW
N2-Y9848 PLATE-PUMP 11RW
25 2V-Y7661 1 PLUNGER SHIELD 4RW, 11RW
26 2A-Z0718 1 GUIDE 4RW, 11RW
27 2P-Z0830 1 SPRING 4RW, 11RW
To Next Page
