SWB7RB, SWB7RBS, SWB8RBL Wafe Bakers
PARTS LIST June 11, 2008, Rev K
IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE
INCLUDE MODEL AND SERIAL NUMBER OF
Some items are included for illustrative purposes only and in certain instances may not be available.
Number
Per
Unit
Description and Model Designation
Star Manufacturing International, Inc.
MODEL
Part
Number
Key
Number
1 2I-Z0057 4 FOOT RUBBER
2 B9-73006 1 LEAD IN CORD 120V 15A
B9-73028 1 LEAD IN CORD 240V
B9-73029 1 LEAD IN CORD 230V CE
3 B9-Z1723 1 COVER-BOTTOM
4 2E-Z1858 1 SWITCH 20A/120V MOLVENO
5 2J-Z1836 1 TIMER
6 B9-73004 1 BODY ASSEMBLY
7 B9-73003 1 YOKE ASSEMBLY
8 B9-73002 1 HINGE TUBE ASSEMBLY
9 2P-Z1735 2 PLUG CAP 3/4
10 2C-Z1734 2 COUPLING 1/4-20
11 2C-08-07-0064 2 ACORN NUT
12 B9-Z1733 2 CUP 7" SWB7RB
B9-Z1790 2 CUP 8" SWB8RBL
13 B9-Z1799 2 7" CUP SUPPORT SWB7RB
B9-Z1800 2 8" CUP SUPPORT SWB8RBL
14 2A-Z2644 2 SPACER 3/8X0.035
15 B9-Z1834 2 PLATE SWB7RB
B9-Z2013 2 PLATE SWB8RBL
16 2N-Z1457 2 ELEMENT 500W 120V SWB7RB
2N-Z2720 2 ELEMENT 500W 240V SWB7RB
2N-Z2010 2 ELEMENT 660W 120V SWB8RBL
2N-Z2011 2 ELEMENT 660W 240V SWB8RBL
17 2C-Z1674 2 STUD 1/4-20 X 2 1/4
18 2F-Z1666 1 GRID 7" BELGIAN BOTTOM SWB7RB
2F-Z1768 1 GRID BOTTOM 8" BELGIANLITE SWB8RBL
2F-Z4846 1 GRID 7" BELGIAN COATED SWB7RBS
19 2A-Z6635 1 SHORT HANDLE ROD PLATED
20 2R-09-WB-0027 1 HANDLE BLACK 3/8-16
21 2F-Z1746 1 GRID 7" BELGIAN, TOP SWB7RB
2F-Z1767 1 GRID 8" BELGIANLITE, TOP SWB8RBL
2F-Z4847 1 TOP GRID 7" BELGIAN COATED, TOP SWB7RBS
22 2T-Z2043 1 THERMOSTAT
23 B9-Z1998 1 HOLDER-THERMOSTAT
24 B9-Z1805 1 BRACKET STOPPER
25 B9-73010 1 TOP HINGE ASSEMBLY
B9-Z2664 1 PIN HINGE
26 B9-Z1765 1 LOWER HINGE MACHINED
27 2A-Z2643 2 SPACER 1/4X0.028
28 B9-73011 1 BRACKET REAR ASSEMBLY
29 B9-Z1772 2 TENSION SPRING
30 B9-Z1776 1 PLATE CLAMP
31 B9-73033 1 COLLAR ASSEMBLY
32 2C-Z2613 1 SET-SCREW 10-32X3/8
33 B9-Z1724 1 COVER-BACK
34 2E-05-07-0351 1 TRANSFORMER 115/10V 6VA 120V
2E-05-07-0350 1 TRANSFORMER 230V/10V 6VA 240V
2E-Z2974 1 TRANSFORMER 230V/10V CE 230V CE
