Stara TORNADO 600MD - Procedure for Final Coverage

6.3.5 - Procedure for the final coverages
When applying the final passes, or be it, applying the product on the
extremities/edges of the working area, the Tornado 600MD has an adjustment
resource which goes as follows:
1st) Turn the adjustment screw of the flow positioning disc to a side
orientation, either right or left side, depending on the situation (item 6.3.2);
2nd) Reduce the distribution rate to about 50% (Figure 15).
Figure 15
OVERLAPPING
ZONE
WORK WIDTH
17
