7
SPECIFICATIONS
MOTOR: MODEL #61006 Chinese Petrol Engine, 4.8 kW output. MODEL #61007 Petrol, Honda GXl60, 4.0
kW output.
GOVERNED SPEED: 3,500r/min
DRIVE BELT: 1 x ’A’ section v belt
VIBRATOR FREQUENCY: 5,500 Vibration/min
VIBRATOR CENTRIFUGAL FORCE: 13.0kN
OPERATION MASS: 84kgs
ACOUSTIC NOISE (ACCORDING TO 2000/14/EC
Hand-Arm-Vibration (as per ISO8662, Part 1, m/
s2) 4-9
NAMEPLATE
The following bearing are sealed. Centrifugal
clutch-grease lubricated Vibrator-oil bath
lubricated.
TRANSPORTATION
1. Always shut off engine when transporting machine.
2. Make sure lifting device has enough capacity to hold machine.
3. Use central lifting point (a )when lifting machine.
4. Trolley wheel (b) is used for short distance transportation.
