FEATURES AND FUNCTIONS
5
MAIN COMPRESSOR
AIR TANK
DRAIN
COCK
WHEEL
FAN
COVER
TANK
PRESSURE
GAUGE
OUTPUT
PRESSURE
GAUGE
REGULATOR
VALVE
ONE-WAY
VALVE
DISCHARGE
PIPE
OUTLET
VALVE
COMPRESSOR AREA SET UP
1. Designate a work area that is clean and well-lit. The work area must not allow access by children or
pets to prevent injury.
2. Check for oil leaks and check the oil level.
3. Close the in-line shut-off valve between the compressor and the air hose.
3. Close the in-line shut-off valve between the compressor and the air hose.
4. Turn the power switch ON.
5. Allow the air compressor to build up pressure until it cycles off.
3.5HP
Made with Durable Cylinder 10 Gal
Long Life with Oil-lubricated motor
Delivers 7.2 CFM @ 40 PSI
3.5 CFM at 90 PSI
Maximum Pressure: 125 PSI
Solid Moving Wheels
Factory May change tank color without notice
FEATURES
