User manual
9
Technical specification
Parameters Values
Short range control 2.4GHz Bluetooth Low Energy
Middle range radio control range 868 MHz
Rated radio control distance up to 1500 m
Rated radio notification distance up to 2000 m
Cellular networks range
2G version: 2G GPRS 850, 900, 1800, 1900
4G version: 2G GPRS 900, 1800
3G WCDMA B1 (2100), B8 (900)
4G LTE B1 (2100), B3 (1800),
B7 (2600), B8 (900), B20 (800)
Antenna type Embedded
SIM cards 2 x nanoSIM
GPS+GLONASS receiver sensitivity
–148 dBm —«cold start»
–163 dBm —«hot start»
–165 dBm — in active monitoring
Interfaces
• 2x CAN
• 4 x LIN
• 1 x StarLine coded data bus
• 1 x USB
• 18 programmable channels which can be
set as:
• 15 OC negative outputs – 200 mA max
• 2 positive outputs – 2 А max
• 3 positive inputs
• 3 negative inputs
• 1 universal input
• external temperature sensor input
• external service (valet) button input
• external microphone sensor input
Input voltage 8 – 16 V
Rated current 10 – 15 mA
Tag battery CR2032 3V
Remote key battery LR03 AAA 1.5V
Operating temperature range −40 °С … +85 °С
Main unit dimensions 105 х 63 х 16 mm
Main unit weight 63 g
