Starmatrix Clever-Pool/220V - 3 Installation and Function Explanation; Installation; Installation Sketch and Description

1. Use a cross screwdriver to take
off the screws as shown 3 and plate 1
3.1 INSTALLATION
3.1.1 INSTALLATION SKETCH AND DESCRIPTION
Sketch for Installation
Procedure and instruction
and use screws as shown 2 to fix
3. INSTALLATION AND FUNCTION EXPLANATION
power supply socket.
6、Strictly follow the operation
steps as indicated in this manual.
2、Put plate 1 in your installation place
plate 1.
3、Put the control box 4 on plate 1
and fix with screws as shown 3
4、Connect the plug from pump to the part
as shown 6.
5、Connect plug 5 as shown to the correct
