ATSC (8VSB) Channel Plan - North America
Channel Bandwidth: 6 MHz 8VSB
• Suggested settings for output channel
Frequency 473.000 MHz
Channel Number 66.1
Channel Name HD1
Channel Plan is for reference only. It may vary across countries, areas or cities. Refer to the LCD
menu screen of the Modulator to load country-wise Channel Plan if available.
11
MX-100R, MX-200 and MX-300 HD Modulator
Channel
No.
Frequency
(MHz)
2 57
3 63
4 69
5 79
6 85
7 177
8 183
9 189
10 195
11 201
12 207
13 213
14 473
15 479
16 485
17 491
18 497
19 503
20 509
21 515
22 521
23 527
24 533
25 539
26 545
27 551
28 557
29 563
30 569
31 575
32 581
33 587
34 593
35 599
36 605
37 611
38 617
39 623
40 629
41 635
VHF High Band III
UHF
VHF
Channel
No.
Frequency
(MHz)
42 641
43 647
44 653
45 659
46 665
47 671
48 677
49 683
50 689
51 692
52 701
53 707
54 713
55 719
56 725
57 731
58 737
59 743
60 749
61 755
62 761
63 767
64 773
65 779
66 785
67 791
68 797
69 803
70 809
71 815
72 821
73 827
74 833
75 839
76 845
77 851
78 857
79 863
80 869
81 875
82 881
83 887
UHF
• Mexico ATSC channels are channel 14 to channel 69.
