Channel Plan is for reference only. It may vary across countries, areas or cities. Refer to the LCD
menu screen of the Modulator to load country-wise Channel Plan if available.
J.83B QAM Channel Plan - North America
Channel Bandwidth: 6 MHz QAM
• Suggested settings for output channel
Frequency 783.000 MHz (# 122)
Channel Name HD1
Channel
No.
Frequency
(MHz)
2 57
3 63
4 69
1 75
5 79.00 / 81.00
6 85.00 / 87.00
95 93
96 99
97 105
98 111
99 117
14 123
15 129
16 135
17 141
18 147
19 153
20 159
21 165
22 171
7 177
8 183
9 189
10 195
11 201
12 207
13 213
23 219
24 225
25 231
26 237
27 243
Low
Mid
High
Super
Channel
No.
Frequency
(MHz)
28 249
29 255
30 261
31 267
32 273
33 279
34 285
35 291
36 297
37 303
38 309
39 315
40 321
41 327
42 333
43 339
44 345
45 351
46 357
47 363
48 369
49 375
50 381
51 387
52 393
53 399
54 405
55 411
56 417
57 423
58 429
59 435
60 441
61 447
Hyper
Super
Channel
No.
Frequency
(MHz)
62 453
63 459
64 465
65 471
66 477
67 483
68 489
69 495
70 501
71 507
72 513
73 519
74 525
75 531
76 537
77 543
78 549
79 555
80 561
81 567
82 573
83 579
84 585
85 591
86 597
87 603
88 609
89 615
90 621
91 627
92 633
93 639
94 645
100 651
101 657
102 663
103 669
104 675
105 681
106 687
107 693
108 699
109 705
110 711
111 717
Ultra
Jumbo
Hyper
Channel
No.
Frequency
(MHz)
112 723
113 729
114 735
115 741
116 747
117 753
118 759
119 765
120 771
121 777
122 783
123 789
124 795
125 801
126 807
127 813
128 819
129 825
130 831
131 837
132 843
133 849
134 855
135 861
136 867
137 873
138 879
139 885
140 891
141 897
142 903
143 909
144 915
145 921
146 927
147 933
148 939
149 945
150 951
151 957
152 963
153 969
154 975
155 981
156 987
157 993
158 999
Jumbo
12
MX-100R, MX-200 and MX-300 HD Modulator
