DVB-T Channel Plan - Europe, Colombia & Asia
Channel Bandwidth: 7 MHz or 8 MHz QAM, QPSK
• Suggested settings for output channel
Frequency 474.000 MHz (CH-21)
Channel Name HD1
Channel Plan is for reference only. It may vary across countries, areas or cities. Refer to the LCD
menu screen of the Modulator to load country-wise Channel Plan if available.
13
MX-100R, MX-200 and MX-300 HD Modulator
Note: * indicates channels with 7 MHz bandwidth.
Channel
No.
Frequency
(MHz)
CH-05 177.5*
CH-06 184.5*
CH-07 191.5*
CH-08 198.5*
CH-09 205.5*
CH-10 212.5*
CH-11 219.5*
CH-12 226.5*
CH-21 474
CH-22 482
CH-23 490
CH-24 498
CH-25 506
CH-26 514
CH-27 522
CH-28 530
CH-29 538
CH-30 546
CH-31 554
CH-32 562
CH-33 570
CH-34 578
CH-35 586
CH-36 594
CH-37 602
CH-38 610
CH-39 618
CH-40 626
CH-41 634
Channel
No.
Frequency
(MHz)
CH-42 642
CH-43 650
CH-44 658
CH-45 666
CH-46 674
CH-47 682
CH-48 690
CH-49 698
CH-50 706
CH-51 714
CH-52 722
CH-53 730
CH-54 738
CH-55 746
CH-56 754
CH-57 762
CH-58 770
CH-59 778
CH-60 786
CH-61 794
CH-62 802
CH-63 810
CH-64 818
CH-65 826
CH-66 834
CH-67 842
CH-68 850
CH-69 858
• UK DVB-T channels start from CH-21.
• New Zealand DVB-T channels start from CH-26.
Channel
No.
Frequency
(MHz)
CH-06 177.5
CH-07 184.5
CH-08 191.5
CH-09 198.5
CH-09A 205.5
CH-10 212.5
CH-11 219.5
CH-12 226.5
CH-28 529.5
CH-29 536.5
CH-30 543.5
CH-31 550.5
CH-32 557.5
CH-33 564.5
CH-34 571.5
CH-35 578.5
CH-36 585.5
CH-37 592.5
CH-38 599.5
CH-39 606.5
CH-40 613.5
CH-41 620.5
CH-42 627.5
CH-43 634.5
CH-44 641.5
Channel
No.
Frequency
(MHz)
CH-45 648.5
CH-46 655.5
CH-47 662.5
CH-48 669.5
CH-49 676.5
CH-50 683.5
CH-51 690.5
CH-52 697.5
CH-53 704.5
CH-54 711.5
CH-55 718.5
CH-56 725.5
CH-57 732.5
CH-58 739.5
CH-59 746.5
CH-60 753.5
CH-61 760.5
CH-62 767.5
CH-63 774.5
CH-64 781.5
CH-65 788.5
CH-66 795.5
CH-67 802.5
CH-68 809.5
CH-69 816.5
• Australia DVB-T channels - 7 MHz bandwidth.
