StarMax MX-100R - Page 16

ISDB-T(b) Channel Plan - South America
Channel Bandwidth: 6 MHz QAM, DQPSK, QPSK
• Suggested settings for output channel
Frequency 473.143 MHz (CH-14)
Channel Name HD1
Channel Plan is for reference only. It may vary across countries, areas or cities. Refer to the LCD
menu screen of the Modulator to load country-wise Channel Plan if available.
Channel
No.
Frequency
(MHz)
CH-39 623.143
CH-40 629.143
CH-41 635.143
CH-42 641.143
CH-43 647.143
CH-44 653.143
CH-45 659.143
CH-46 665.143
CH-47 671.143
CH-48 677.143
CH-49 683.143
CH-50 689.143
CH-51 695.143
CH-52 701.143
CH-53 707.143
CH-54 713.143
CH-55 719.143
CH-56 725.143
CH-57 731.143
CH-58 737.143
CH-59 743.143
CH-60 749.143
CH-61 755.143
CH-62 761.143
CH-63 767.143
CH-64 773.143
CH-65 779.143
CH-66 785.143
CH-67 791.143
CH-68 797.143
CH-69 803.143
14
MX-100R, MX-200 and MX-300 HD Modulator
Channel
No.
Frequency
(MHz)
CH-07 177.143
CH-08 183.143
CH-09 189.143
CH-10 195.143
CH-11 201.143
CH-12 207.143
CH-13 213.143
CH-14 473.143
CH-15 479.143
CH-16 485.143
CH-17 491.143
CH-18 497.143
CH-19 503.143
CH-20 509.143
CH-21 515.143
CH-22 521.143
CH-23 527.143
CH-24 533.143
CH-25 539.143
CH-26 545.143
CH-27 551.143
CH-28 557.143
CH-29 563.143
CH-30 569.143
CH-31 575.143
CH-32 581.143
CH-33 587.143
CH-34 593.143
CH-35 599.143
CH-36 605.143
CH-37 611.143
CH-38 617.143
