DVB-C (J.83A/C QAM) Channel Plan
Channel Bandwidth: 8 MHz QAM
• Suggested settings for output channel
Frequency 778.000 MHz (# 88)
Channel Name HD1
Channel Plan is for reference only. It may vary across countries, areas or cities. Refer to the LCD
menu screen of the Modulator to load country-wise Channel Plan if available.
Channel
No.
Frequency
(MHz)
1 52.5
2 60.5
3 68.5
4 80
5 88
13 115
14 123
15 131
16 139
17 147
18 155
19 163
6 171
7 179
8 187
9 195
10 203
11 211
12 219
20 227
21 235
22 243
23 251
24 259
25 267
26 275
27 283
28 291
29 299
30 307
31 315
32 323
33 331
Channel
No.
Frequency
(MHz)
34 339
35 347
36 355
37 363
38 371
39 379
40 387
41 395
42 403
43 411
44 419
45 427
46 435
47 443
48 451
49 459
50 474
51 482
52 490
53 498
54 506
55 514
56 522
57 530
58 538
59 546
60 554
61 562
62 570
63 578
64 586
65 594
66 602
Channel
No.
Frequency
(MHz)
67 610
68 618
69 626
70 634
71 642
72 650
73 658
74 666
75 674
76 682
77 690
78 698
79 706
80 714
81 722
82 730
83 738
84 746
85 754
86 762
87 770
88 778
89 786
90 794
91 802
92 810
93 818
94 826
95 834
96 842
97 850
98 858
99 866
