S8010
117
ENGLISH
The Drill/Driver Starrett S8010 has a metallic Clip system (fi gure 05) that
allows the user to fi t the machine in the belt of his pants.
This system can be installed or removed as needed by the user himself,
following the procedures below.
1. ALIGN the Belt Clip with side threaded hole of the machine (fi gure 05);
2. INSERT and TIGHTEN the fi xing screw securely with a Phillips screwdriver.
1. USE a Phillips screwdriver to RELEASE the screw that clamp the Clip;
2. REMOVE the screw and the Clip.
BELT CLIP REMOVAL:
The Drill/Driver has a Keyless Chuck
type.
It allows tightening or loosing the chuck
without specifi c keys. The arrows shown
in fi gure 06 indicate the sense of rotation
on the body to open or close the chuck.
See PROCEDURE TO INSTALL A DRILL,
HOLE SAW AND BIT section, for safe
tightening the Chuck.
17 19 21 23
GRIP
RELEASE
KEYLESS
CHUCK
KEYLLES CHUCK:
FIG 06
