FPU-16 Feeder Protection Unit Rev. 2
Pub. FPU-16-M, November, 1997 Downloaded from the Internet, see Disclaimer.
Fuse-Selection Chart:
FUSE HZ VOLTAGE RATING DESCRIPTION
F1, F2 60 120/240 8 A, 250 Vac ¼" x 1¼" CSA/UL Normal
50 IEC 127/I F Quick Acting
F3 60 120 100 mA, 250 Vac ¼" x 1¼" CSA/UL Time
240 62 mA, 250 Vac Delay
SW 50 120 160 mA, 250 Vac IEC 127/III T Time Lag
240 80 mA, 250 Vac
F3
D1
12 Vdc 2A, 250 Vac ¼" x 1 ¼" CSA/UL Time Delay
5 x 20 mm IEC 127/III TD
F3
D2
24 Vdc 1 A, 250 Vac ¼" x 1 ¼" CSA/UL Time Delay
5 x 20 mm IEC 127/III TD
F3
D4
48 Vdc 0.5 A 250 Vac ¼" x 1 ¼" CSA/UL Time Delay
5 x 20 mm IEC 127/III TD
All specifications are subject to change without notice.
