Installing the Side Panels
Note: At least two people are required when removing or
reinstalling the Side Panel.
1. While supporting the weight of the Side Panel align the
bottom lip of the Side Panel with the lip on the Rack’s
Frame.
2. Slide the lip of the Side Panel into the lip on the Rack’s
Frame.
3. Push the top of the Side Panel into the Rack’s Frame until
you hear it click (lock) into place.
Grounding the Rack
1. Insert an M6 Screw through the grounding point on the
Grounding Wire (sold separately) and into the Ground
Hole, located on the bottom of the Rack just inside of either
the front or rear Door Frame.
2. Run the Grounding Wire under the Rack’s Frame to prevent
obstructing the Rack Door from closing.
3. Connect the Grounding Wire to an earth ground
connection.
