4. Remove the Cage Nuts from the Depth Adjustment Rails
by applying pressure to both sides of the Cage Nut.
- or -
Use a Cage Nut Wrench to remove the Cage Nuts from the
Depth Adjustment Rails.
5. Once you have determined the mounting depth reinstall the
Cage Nuts into the Depth Adjustment Rails.
6. Slide the Mounting Rail along the Depth Adjustment Rail
aligning it with the Cage Nuts inserted in step 5.
Notes: The distance between each of the Mounting Rail
Adjustment Holes is .827” (21 mm).
7. Insert the M6 Screws through the Mounting Rail and into
the Cage Nuts.
8. Use a Phillips Head Screwdriver to tighten the M6 Screws.
