StarTech.com USB3SDOCKHDV - Hardware Overview; Rear View; Side Views

Instruction Manual
2
6. Microphone Port
7. USB 3.0 Downstream Port
8. Security Lock Hole
9. USB 3.0 Upstream Port
10.DC IN Port
1 2 3 4
5
6 7
1. DVI-D Port
2. HDMI Port
3. VGA Port
4. 10/100/1000Mbps LAN (RJ-45) Port
5. Headphone Port
Rear View
Side Views
8 9 7
10
