STARTEK FM220U - 4. Specifications and System Requirements; 4.1 Specifications; 4.2 System Requirements

FM220U User Guide Doc. FM220U_Win_1.0
2
4. Specifications and System Requirements
4.1 Specifications
Parameter
Value
Unit
Sensors
CMOS
-
Scanning
1/15
s
Image resolution
500
DPI
Image capture format
13.3 x 16.4
mm
Scanner output image size
264 x 324
Pixels
Gray Level
8bits/pixel, max 256 gray scales
-
Image ratio of length to width
1:1
-
Power supply
Fingerprint Sensing
200
mA
Standby mode
60
mA
Interface
USB2.0
-
Dimension
80 x 41 x 40
mm
Weight
100
g
Distortion
<1
%
Temperature
(without external enclosure)
0~50
°C
Humidity(non-condensing)
<90%
-
Scanning light
source((940nm))
Infrared red
-
Operating volts(USB
connector)
5
V
ESD
15
KV
4.2 System Requirements
USB 2.0 port, 256MB RAM
If you are installing an application based on platforms other than Windows,
such as Android or Linux, please refer to the documentation provided by
the maker of the application program.
