Starway modena - Product Overview and Specifications; Technical Specifications; Product Introduction; Physical Dimensions

Page 39
technical sPeciFications :
• Zoom 4.35 ° - 32 ° beam (5 ° - 55 ° Field)
• Illuminance: 17000 Lux at 5M / 4.35 °
• Max ux 3650 Lumens
• Cooling: Forced air 3 modes
• DMX modes: 15/19/21/25/41 / 69ch
• Protocols: DMX / Artnet / sACN / Klingnet / RDM
• 20 internal pattern programs
• BColor System
• Flicker Free: Led frequency adjustable from 900 to 25000Hz
• Dmx In / Out connectors: 2 x XLR5.
• Artnet / sACN / Klingnet -connectors: 2 x RJ45
• Dimensions W x D x H: 292MM * 180MM * 334MM (including handles)
256MM*180MM*334MM (without handles)
• Net weight: 7.38Kg with Omega grip.
• Max power: 300W
Introduction:
This product has been dedicated for indoor use only.Particularly suitable for scenes. TV set or
clubs. Controllable in DMX these projectors can be controlled byany DMX console.
DIMENSIONS (mm) :
329
297
89
223
185
107
132 177
89
223
207
349
180
252
184
159
83
177
257
