Starway modena - Menu System and Configuration

Page 46
MENU
Receive
Adress mode
1 address This choice is only 1 address
2 address This choice is 2 address
Set Address
Adress Fixture A001~AXXX
Address Leds A001~AXXX
User Mode
User Mode
Basic 8B
Basic 16B
Standard 8B
Standard 16B
Pixel 8B
Pixel 16B
User A
User B
User C
Edit A
Max Chan
PAN, TILT, .../...
Edit B
Edit C
Function
Status
No DMX Mode Hold/Auto/black
P.Reverse ON/OFF
T.Reverse ON/OFF
Pan Degree 630/540
Feedback ON/OFF
Move.Spd Speed 1~ 4
Hibernation OFF, 01M~99M, 15M
Fixture ID
ServicePIN 000-255 (050)
Universe 000-255
UnitIPAddr 002.000.000.002
Mask Addr 255.000.000.000
Protocol Set
ArtNet
sACN
KlingNet Enable/Disable
Net Switch On/Off
Dim Mode Standard/Stage/TV/Architectural/Theatre
Temp. C/F
Celsius
Fahrenheit
Dim Curve
LINEAR
Square
Inverse Square
S-CURVE
THE VALUES IN RED ARE DEFINED BY DEFAULT IN THE MENU
AND RELOADED AS IN THE CASE OF
«RELOAD DEFAULT SETTINGS»
