Starway modena - DMX Channel Charts; Basic 8 B DMX Chart

Page 53
DMX CHART
Basic 8B
1 Pan 000~255
Pan
2 Pan ne 000~255
3 Tilt 000~255
Tilt
4 Tilt ne 000~255
5 P/T Speed
000~225 Max to min speed
226~235 Blackout by movement
236~255 Idle
6 Dimmer 000~255 General dimmer
7 Dimmer Fine 000~255 General dimmer ne
8 Strobe
000~009 Shutter closed
010~019 Shutter open
020~068 Strobe effect slow to fast
069~79 Shutter open
80~128 Pulse-effect in sequences
129~139 Shutter open
140~188 Random strobe effect slow to fast
189~199 Shutter open
200~248 Random ash Pixel slow to fast
249~255 Shutter open
9 Zoom 000~255 Zoom
10 Dim Modes
000~020 Default unit setting
021~040 Standard
041~060 Stage
061~080 TV
081~100 Architectural
101~255 Theatre
11 Control
000~005 Idle
006~017 Invert Pan on (Hold 3s)
018~029 Invert Pan off (Hold 3s)
030~041 Invert Tilt on (Hold 3s)
042~053 Invert Tilt off (Hold 3s)
054~065
Fan Silent (Hold 3s)
The fan turn always at same low speed
066~077
Fan Auto (Hold 3s)
The fan speed increase with temp
078~089
Fan High (Hold 3s)
The fan turn always at same high speed
090~101 Linear Dimmer Curve (hold 3s)
102~113 Square Dimmer Curve (hold 3s)
114~125 Inv-Square Dimmer Curve (hold 3s)
126~131 S - Dimmer Curve (hold 3s)
132~137 Led Freq. 900 Hz (hold 3s)
