Standard 8B
1 Pan 000~255
Pan
2 Pan ne 000~255
3 Tilt 000~255
Tilt
4 Tilt ne 000~255
5 P/T Speed
000~225 Max to min speed
226~235 Blackout by movement
236~255 Idle
6 Dimmer 000~255 General dimmer
7 Dimmer Fine 000~255 General dimmer ne
8 Strobe
000~009 Shutter closed
010~019 shutter open
020~068 Strobe effect slow to fast
069~079 Shutter open
080~128 Pulse-effect in sequences
129~139 Shutter open
140~188 Random strobe effect slow to fast
189~199 Shutter open
200~248 Random ash Pixel slow to fast
249~255 Shutter open
9
Virtual
Wheel Color
forground
000-010
White macro
RGBW channels need to are at
255 value to obtain the good color
temperature. Is possible to ajust the
color with RGBW
See sheet Forground
Color Wheel
Page 72
011-250
Virtual color wheel
Only W channel can modify the color
saturation
251-253
Color Wheel rotation between the color
level 12 to 250
254-255 Color rotation backward
10
Virtual
Wheel Color
Background
000-010
White macro
The chosen white is obtained only when
a patern or auto program is used, Is not
possible to adjust the color
See sheet
Background Color
Wheel
Page 73
011-251
Virtual color wheel
The chosen color is obtained only when
a patern or auto program is used, Is not
possible to adjust the color saturation
252-253
Color Wheel rotation between the color
level 11 to 250
254-255 Color rotation backward
11
Colour Fade/
Speed
000-255 Fade between colors/ Speed from fast to slow.
