Fireaway Inc. Version 1
5852 Baker Road 10/2017
Minnetonka, MN 55345 P/N 19112
7
PN 830001 – Dual Detection Zones and Dual Releasing Zones. Either detection zone
will actuation both actuation zones. A single dedicated Manual Input Switch will also
actuate both actuation zones.
PN 830001-01 – Dual Detection Zones and Dual Releasing Zones. Each detection zone
will actuate individual separate actuation zones. A single dedicated Manual Input Switch
will also actuate both actuation zones.
Detection Zones and Actuation zones cables are identified at the SDRP primary cable
with a white label and colored ty-wraps.
Figure 4 - SDRP mounting hole pattern
