To avoid deformations of the workpieces during
fixing thereof, the use of wooden profiles being
easily applicable to the movable jaws of the clamps
is advised. Clamps can be easily extracted and
leave the working surface totally clear.
For cutting long workpieces under safe conditions it
is essential to hold them with additional supports.
11.Limits regarding the workpiece
size
Limits for all models as included in the
present manual
Information!
Model SC264W lacks an upper table so that the
limit regarding the workpiece size for cutting
operations on the upper table is not applicable to
this model.
12.General instructions for use
Warning!
1. Do NOT use the machine if it is in a bad condition
or lacks parts including the prescribed upper
guards (the illustrations of the present manual
may be used as an orientative guide). Unplug it,
remove it from the working area and immediately
send it to an authorized technical service.
2.Know and comply with all safety measures before
you start the machine.
3. Obligatory used of aspiration particle system
when cutting the wood.
Starting and stopping the machine
Information
1.The machine is provided with a locking button 3
for starting allowing the motor to run without
needing to push switch 2 permanently.
2.The equipment is provided with a safety module
protecting it against unexpected starts. If, whilst
the machine is running, the supply of electrical
power should cease, the machine will not start
after reestablishment thereof. To release the
protection push the starting button 2 twice.
3.Except for SCE1650W all models are single
speed.
Model SCE1650W is provided with an electronic
module that provides the electrical machine with the
following electromechanical improvements:
1.Smooth starting curve
2.Automatic current limitation against overloads.
3.Continuous speed regulation with an adjusting
wheel at the motor body with 5 default values.
Warnings!
1.Avoid locking whenever possible (button 3).
2.Never leave running machine unattended.
3.Never start the machine with locked disk and,
before starting a cut, always wait until the cutting
disk has reached its maximum speed.
4.Before stopping the machine the disk must be
clear and be rotating freely.
Starting with the manual switch
1.Push switch 2 to actuate the motor.
Stopping the machine when actuated with the
manual switch
1. Stop pushing switch 2.
Starting with locking
1.Push switch 2.
2.Push locking button 3 whilst keeping switch 2
pushed.
3.Release switch 2.
IMAGES
ENGLISH
32
32
A B N
Limit of the workpiece
size in mm
SC250W:
size in mm
Limit of the workpiece
Limit of the workpiece
size in mm
SC2500W:
M
SCE1650WMC:
