WINCH MANUAL
SPECIFICATIONS

EN
SPECIFICATIONS
Rated line pull 4500 lbs (2041 kgs)
Gear reduction ratio 166:1
Motor 12V: Input: 2.5kW / 3.4hp; Output: 1.1 kW / 1.4hp
Overall dimensions 408 ×125 ×168 mm (16.1”×4.92”×6.6”)
Drum size Ø50.4mm×125mm (Ø2.0”×4.9” )
Cable
Synthetic rope Wire rope
Ø6mm×15.0m (Ø15/64”×49.2’) Ø6mm×14.5m (Ø15/64”×47.6’)
Net Weight
Synthetic rope Wire rope
12.5kg (27.5 lbs) 15.5kg (34.1lbs)
Line Pull, Speed, Amperes, Volts (First layer):
Line Pull Ibs (kgs) Line Speed ft/min (m/min) Current A (12V DC)
0 12.8(3.9) 28
1000(454) 9.8(3.0) 80
2000(907) 8.5(2.6) 120
3000(1361) 6.9(2.1) 160
4500(2041) 4.6(1.4) 220
Layers, Line Pull and Rope Capacity
Layer Rated line pull lbs (kgs) Total rope on the drum ft (m)
1 4500(2041) 12.2(3.7)
2 3841(1742) 26.2(8.0)
3 3310(1501) 41.9(12.8)
4 2907 (1319) 47.6(14.5)
45STS12 / 45STA12
