Stealth 35STS12 - Specifications

WINCH MANUAL
SPECIFICATIONS

SPECIFICATIONS
Rated line pull 3500 lbs (1588 kgs)
Gear reduction ratio 170:1
Motor 12V: Input: 2.4kW / 3.2hp; Output: 1.0 kW / 1.3hp
Overall dimensions 348×116×165mm (13.7”×4.6”×6.5”)
Drum size Ø37mm×80mm (Ø1.46”×3.15”)
Cable
Synthetic rope Wire rope
Ø5mm×14m (Ø13/64”×46.0’ Ø5.4mm×12.8m (Ø7/32”×42.0’)
Net Weight
Synthetic rope Wire rope
8.5kg (18.7 lbs) 10.5kg (23.1 lbs)
Line Pull, Speed, Amperes, Volts (First layer):
Line Pull Ibs (kgs) Line Speed ft/min (m/min) Current A (12V DC)
0 10.2(3.1) 20
1000(454) 8.9(2.7) 75
2000(907) 7.5(2.3) 130
3500(1588) 4.6(1.4) 200
Layers, Line Pull and Rope Capacity
Layer Rated line pull lbs (kgs) Total rope on the drum ft (m)
1 3500(1588) 5.9(1.8)
2 2789(1265) 13.5(4.1)
3 2319(1052) 22.0(6.7)
4 1984 (900) 31.2(9.5)
5 1733 (786) 42.0(12.8)
35STS12 / 35STA12
