Stealth 35STS12 - Winch Parts List

WINCH MANUAL
SPECIFICHE TECNICHE

# sku Qty Description
1 ST0350100 1 Motor Assembly
2 ST0350001 4 Cap Screw M8 x 16
3 ST0350002 1 Transition Shaft
4 ST0350004 2 Tie Bar
5 ST0350004 1 Hexagonal Shaft
6 SST0350006 1 Front Bush Drum
7 ST0350006 6 Thick Flat Washer Φ6
8 ST0350007 6 Locking Washer Φ6
9 ST0350008 1 Screw M6 x 8
10 ST0350009 2 Cap Screw M6 x 70
11 ST0350010 1 Drum
12 ST0350011 1 Rear Bush Drum
13 ST0350012 1 Front Thrust Washer
14 ST0350013 1 Gear Ring Output
15 ST0350200 1 Gear Carrier Assembly
16 ST0350014 1 Gear Ring
17 ST0350015
1 Gear Housing / End
Bearing
18 ST0350016 1 Bearing Holder
19 ST0350017 1 Roller Bearing
20 ST0350018 1 Clutch axes
21 ST0350019 1 Cam Clutch Gear
22 ST0350020 1 Spring
23 ST0350021 1 Cover Clutch Housing
24 ST0350022 1 Roller Bearing
25 ST0350023 1 Elastic Collar
26 ST0350024 1 Clutch Handle
27 ST0350025 1 Locking Washer Φ5
28 ST0350026 1 Cap Screw M5 x 12
29 ST0350027 4 Cap Screw M6 x 25
30 ST0350028 4 Hex Flange Nut M8
31 ST0350029 4 Locking Washer Φ8
32 ST0350030 4 Thick Flat Washer Φ8
33 ST0350300
1 Roller Fairlead
(Steel Rope)
34 ST0350031 1 Mounting Channel
# sku Qty Description
35 ST0350032 2 Cap Screw M8 x 20
36 ST0350033 2 Cap Screw M8 x35
37 ST0350034
1 Aluminum Fairlead
(Synthetic Rope)
38 ST0350034 2 Terminal Protector
39
ST0350400-1
1 Cable Assembly
(Steel Rope)
ST0350400-2
Cable Assembly (Synthetic
Rope)
40 ST0350035 1 Strap
41 ST0350036 1 Wireless Switch Receiver
42 ST0350037 1 Switch
43 ST0350500
1 Control Section Of U Type
Winch
WINCH PARTS LIST 35STS12 / 35STA12
