WINCH MANUAL
SPECIFICHE TECNICHE

WINCH PARTS LIST 45STS12 / 45STA12
# sku Qty Description
1 ST0450001 2 Terminal Protector
2 ST0450100 1 Motor Assembly
3 ST0450002 1 Screw M4 x16
4 ST0450003 2 Locking Washer Φ4
5 ST0450004 1 Stand Bar
6 ST0450005 1 Coupling I
7 ST0450006 1 Spring
8 ST0450007 1 Coupling II
9 ST0450008 1 Spring
10 ST0450009 2 Ring Seals
11 ST0450010 2 Bushing-Drum
12 ST0450011 1 Hexagonal Shaft
13 ST0450012 1 Screw M6 x 8
14 ST0450200 1 Drum Assembly
15 ST0450013 1 End Bearing
16 ST0450014 1 Screw M4 x25
17 ST0450015 1 Gasket
18 ST0450016 1 Gear-Ring
19 ST0450300
1 Gear Carrier Assembly
(Output)
20 ST0450400
1 Gear Carrier Assembly
(Intermediate)
21 ST0450500
1 Gear Carrier Assembly
(Input)
22 ST0450017 1 Gear—Input Sun
23 ST0450018 1 Gasket
24 ST0450600 1 Clutch Handle Assembly
25 ST0450019 4 Thick Flat Washer Φ6
26 ST0450020 6 Locking Washer Φ6
27 ST0450021 2 Screw M6 x100
28 ST0450022 4 Screw M6 x25
29 ST0450023 2 Tie Bar
30 ST0450024 2 Hex Flange Nut M10
31 ST0450700
1 Roller Fairlead
(Steel Rope)
32 ST0450025 1 Mounting Channel
33 ST0450026 2 Screw M10 x 20
# sku Qty Description
34 ST0450027 4 Thick Flat Washer Φ8
35 ST0450028 4 Locking Washer Φ8
36 ST0450029 4 Screw M8 x25
37 ST0450030
1 Aluminum Fairlead
(Synthetic Rope)
38
ST0450800-1
1 Cable Assembly
(Steel Rope)
ST0450800-2
Cable Assembly
(Synthetic Rope)
39 ST0450031 1 Strap
40 ST0450032 1 Wireless Switch Receiver
41 ST0450033 1 Switch
42 ST0450900
1 Control Section Of U Type
Winch
