STEALTH ELECTRIC BIKES OWNER’S MANUAL
V 2.4 PAGE | 12
The main connector simply pushes together.
When connecting the charge port, be sure that the correct connection is made and that the red and green connectors line
up. Install locking pin so that the plug does not detach.
6.1 INSTALL THE BATTERY (STEALTH P-7 ONLY)
The Battery for the P-7 can be accessed from underneath the frame by removing the retaining plate held on by 4 button
head screws. Carefully turn the bike upside down so that it is resting on its handlebars and seat. This will allow for easier
installation.
