Steamfast SF-210 - Assembling Your Everyday Steam Cleaner; Connecting Jet Nozzle

6
|
ENGLISH
Assembling Your
Everyday Steam Cleaner
CONNECTING JET NOZZLE
WARNING: DO NOT attempt to connect any accessories while unit is emitting steam.
Doing so could result in burns or other injury.
1. Align Jet Nozzle with Steam Nozzle as shown (FIGURE 1-A). Jet Nozzle should be sideways
90º counter-clockwise from it’s nal position. Guide keys on Jet Nozzle should line up with key
slots on base of Steam Nozzle (FIGURE 1-B).
2. Slide Jet Nozzle onto Steam Nozzle - guide keys should t into key slots. Push Jet Nozzle on
as far as it will go (FIGURE 2-A). Rotate Jet Nozzle 90ºclockwise, turning it until it will move
no further (FIGURE 2-B).
FIGURE 1
FIGURE 2
1-A
2-A
2-B
1-B
KEY SLOTS
GUIDE KEYS
