Steamtec KSA-Elegance - Page 7

________________________________________________________________________________
TOLO SAUNA info@tolosauna.com www.tolosauna.com
7
N
Output1
Input
Output2
LAMP DC12V LED
Room Temp
Sensor
KSA-Elegance
CONTROLLER
Over-heat
protection
N
WV
Input
U
N
No connecting
L3L2L1 N
Output3
N
L3L2L1 N NL1 L2 L3
Sauna heater
NL1 L2 L3
380-415V
3N～ 50/60Hz
SAUNA HEATER
18～22.5kW
U3 V3 W3 U2 V2 W2 U1 V1 W1
Figure 6
POWER INPUT
CONNECT TO SAUNA HEATER
18KW -27 KW
European
380-415V 3 Phase
