6.2.2 Symbols used in the system graphics
The following table describes the symbols used in the system graphics ( in Fig. 8).
Symbol Description Symbol Description
Pipework Pump, switched on
Collector (array) Pump, switched off
Maximum collector tempera-
ture reached
Temperature sensor
Storage tank Back-up heating
Swimming pool Solid fuel boiler
Sufficient solar irradiation
available for loading
Domestic water outlet
Drainback
Symbols Description
1
2
3
4
Drainback tank
Symbol Short startup for drainage assistance
Symbol Filling
Symbol Draining
+ Symbol Stabilising
6.2.3 Settings menu
The settings menu ( in Fig. 8) contains the following entries:
S
yst
F
unc
P
ara
