Preface
Many thanks for purchasing this Steinbach product. We continually develop
and enhance our items. However, should this product be faulty, we apologise for
any inconvenience and politely ask you to get in contact with our service centre.
Read the operating manual and store it safely
Operating manual for lter system Speed Clean Active Balls +
This instruction manual relates to the product stated above. It contains
important information on using your product for the rst time and how to
operate it. Carefully read through the instruction manual, particularly the
safety instructions, before using this product. Non-compliance with this
instruction manual may lead to major injuries or damage to your product. The
instruction manual is based on standards and regulations applicable within
the European Union. If the product is being used abroad, please follow any
country-specic guidelines and laws. Store the instruction manual in a safe
place for later consultation and submission to third parties, where applicable.
Intended use
The product is exclusively for private use and not suitable for commercial use.
The lter system has been designed exclusively to clean pool water and to remove
visible impurities. The system is suitable for all standard swimming pools which
have a 32/38 mm diameter hose connection. Use your product only as described
in this manual. Any other use is considered improper use and may lead to
personal injury or damage to property. This item is not a toy. The manufacturer or
retailer assumes no liability for damage resulting from improper or incorrect use.
Warnings and safety instructions
Read and observe all instructions. Non-compliance with these warnings
and instructions may result in damage to property, severe personal
injury or even death. These product warnings, instructions and
safety regulations are extensive but can not cover all potential risks
and dangers and are thus not to be considered exhaustive. Please
be cautious and assess potential dangers appropriately. Incorrect
use/handling of the product can lead to life threatening situations.
Caution! Leave repairs to experts in order to prevent hazards. Consult
a specialist workshop. Liability is waived and warranty claims expire
if repairs are carried out independently of if the product is improperly
installed or used incorrectly. Only original parts corresponding to
the original product specications may be used during repairs.
WARNING! Hazardous for children and persons with reduced
physical, sensory or mental abilities (such as the handicapped,
elderly individuals with impaired physical and mental abilities), or
those with a lack of experience and knowledge. Children must never
play with the product. Cleaning may not be performed by children
and persons with reduced physical, sensory or mental abilities.
NOTE! Risk of damage! This product may be damaged through improper use.
CAUTION! THIS BAG IS NOT A TOY!
Please keep away from babies and small children! Do not pull over your
head! Choking hazard!
Danger of electrocution! Faulty electrical installation or too high mains
voltage can lead to electrocution. Only connect the product if the mains
voltage on the socket corresponds to the technical specications.
Only connect this product using an easily accessible socket to ensure
it can be rapidly disconnected from the mains in the event of a fault.
Do not operate the product if it exhibits visible damage or the mains
cable/plug is defective. As additional protection, it is recommended
to install a residual current device (FI/RCD) with a tripping current
of no more than 30 mA. Consult with an electrician for advice.
Only open the product as described in this manual. Leave repairs to experts
in order to prevent hazards. Consult a specialist workshop. Liability is
waived and warranty claims expire if repairs or changes to the product
are carried out independently of if the product is improperly connected
or operated incorrectly. This product features electrical and mechanical
parts which are indispensable for protecting against potential hazards.
Never touch the plug with wet hands. Never pull out the plug from
the socket using the cable - always pull on the plug. Keep the
product, plug and all cables away from open res and hot surfaces.
Lay the cable so that it does not pose a tripping risk and do not
place it under the ground. Lay cables in such a way that they will
not be damaged by lawn mowers and other similar devices. Do
not bend the cable and do not lay it over sharp edges. Do not use
an extension cable, multiple socket adapters or other adapters.
Filtration systems must not be operated dry (i.e. without any water)! If
dry run there is no guarantee replacement! Never place the pump or
lter into the pool. The lter pump must be switched off before every
switching operation using the 7-way valve! The ltration system must
not be used if there are people in the water! Install the ltration system at
a suitably safe distance from the pool to prevent children from using the
system as a means of entering the pool. Do not immerse the lter system,
power cable or plug in water or in any other liquids. The lter system’s
pump is designed to ensure good protection against foreign bodies and
water spray. However, it should still be installed in such a way to ensure
adequate protection from the weather. Never carry out any work on the
ltration system while it is still connected to the mains. Hazards posed by
the suction of the pump can lead to serious injury and death if adequate
precautions are not taken. Do not block the suction openings on the
pump or in the pool since this may lead to serious injury or even death.
Check the scope of delivery
NOTE! Risk of damage! The product may be damaged if you open
the packaging with a sharp knife or other sharp objects without
due care and attention. Please open the packaging very carefully.
■ Remove the product from the packaging.
■ Check that all included items have been delivered in full. Sketch/Photo L1.
■ Check whether the item, or parts thereof, show signs of damage. If there
is any damage, do not use the product. Please get in contact with the
service address stated at the end of the manual.
Operation
The Filter Balls used in the lter tank provide long-lasting ltration of dirt particles
and oating debris. As the water ows through the Filter Balls in the lter tank,
dirt particles are deposited in the sand and thus ltered out of the pool water. The
puried water ows through the 7-way valve back into the pool via the return pipe.
To operate the lter system you need a skimmer (surface
skimmer). Either a built-in skimmer (installation in the pool
wall) or a suspended skimmer (attachment to the pool wall).
Location determination
The installation location of the lter system between the skimmer and inlet
nozzle should ensure a sufcient safety distance to the pool wall. We recom-
mend placing the lter system on a level base (for example, washed concrete
slabs or similar). The correct alignment must be checked with a spirit level.
Under no circumstances may you place your lter system in a sunken area
or directly in the green area. (Risk of ooding and / or risk of hot running of
the lter pump). If you have partially or completely sunk your pool system, it is
advisable to place the lter system in a lter shaft, which connects directly to
the pool area. If your lter system is housed in a lter shaft, it must be ensured
that the shaft does not get ooded. For this purpose, we recommend adding
drainage (gravel) to the lter shaft so that surrounding and rainwater can seep
away. It would be ideal to connect the pump sump of the lter shaft directly to
a channel or drain (for example submersible pump with oat switch). It is im-
perative to ensure sufcient natural ventilation in the lter shaft. Otherwise, the
formation of condensation could damage the lter pump. The size of the lter
shaft should be selected so that work on the lter system can be carried out.
Installation
Installation of the lter system (Illustration 1) Install the lter system at the
nal installation location. The lter system consists of the following parts:
■ Pump
■ Valve
■ Seal (O-ring)
■ Clamping ring
■ Tank
■ Central pipe
■ Filter screen
■ Drainage screw
■ Centring device (cover for standpipe)
■ Base plate
■ Pressure tube
■ Filter Balls 700 Grammes
