In addition to the daylight component, artificial light is also switched ON and OFF in
relation to whether or not persons are present.
Constant-lighting control can be activated / deactivated via RC 8 remote control and
Smart Remote.
Twilight setting (Fig� 6�1)
The chosen sensor response threshold is infinitely adjustable from approx. 2 to
1000lux.
Control dial set to means twilight mode at approx. 2lux.
Control dial set to means daylight operation / independent of ambient light level.
Teach mode
The control must be set to
at the level of light at which you want the sensor to
respond to movement from now on. The level of ambient brightness measured in this
way will be saved after 10 seconds.
Dazzle guard
This product is equipped with an integrated dazzle guard. If blinded by extraneous
light, this puts the sensor into a brightness-related evaluation mode for 60s.
(➔ "13� Troubleshooting").
LED function
– Normal mode: LED stays OFF
– Test mode: LED lights up on detecting movement
– Remote control: LED flashes approx. 10 times per second
– Permanently ON/OFF: LED ON
Reach setting (Fig� 6�1)
Continuously adjustable
– Control dial set to maximum = max. reach (approx. Ø8m)
– Control dial set to minimum = min. reach (approx. Ø 1 m)
Reach diagram (Fig� 6�2)
Time setting (Fig� 6�1)
The time you want the connected lamp to stay ON for is infinitely adjustable from
approx. 5 sec to a maximum of 15 min. Any movement detected before this time
elapses will restart the timer.
7� Accessories (optional)
User remote control RC 5 EAN
Additional functions RC 5
– Light ON/OFF 4 h
– User reset
– 100 h burn in, 4 h light ON press for ≥ 5 s
– DIM1 - / DIM1 +
– Save scene 1
– Activate scene 1
– Save scene 2
– Activate scene 2
Service remote control RC 8 EAN
Additional functions RC 8
– Time setting CH 1
– Test / normal mode
– Light-level setting: teach
– Night-time operation
– Daylight operation
– Teach-IN
– Reset
– Basic brightness: OFF, night, 1 = 10% ... 6 = 60%, press for ≥ 5 s
Smart Remote EAN 4007841 009151
– Replaces remote controls RC 5 and RC 8
– Control via smartphone or tablet
– Load appropriate app and connect via Bluetooth
– Identify the sensors and read parameters
Additional functions Smart Remote
– Reach: min, 1 – 100%
– Time setting: 5, 10, 15….60 s – 60 min
– Twilight setting: 2 - 1000 lux
– Basic brightness: ON, 10 – 30 min
– Basic brightness level: 10% - 50%
– Main light level: 50% - 100%
– Initial state: behaviour after applying the light ON/OFF supply voltage
– Normal sens
– Low sens
– Burn in
– Sensor
Detailed descriptions are provided in the operating instructions for the particular
remote control.
