STEINEL IR Quattro COM 1 AP User Manual

- 24 -
DIP 4
In the 'ON'-'OFF' setting, the light
can be switched 'ON' and 'OFF'
manually at any time (except in
pulse mode: no manual 'OFF').
In the 'ON' setting, light can no
longer be switched 'OFF' manu-
ally. The stay-'ON' time starts
from the beginning again each
time the button is pressed.
'ON'/'ON'-'OFF' button
DIP 1
Functions – Settings by DIP switch
Test mode has priority over all
other settings on the presence
detector and serves the purpose
of checking for proper working
order as well for testing the de-
tection zone. Irre
spective of am-
bient light level, the presence
detector activates the light to
stay 'ON' for approx. 8 sec. in
response to movement in the
room (blue LED
flashes when
movement is detected). All user-
selected potentiometer settings
apply in normal mode. The pres-
ence detector can also be set by
means of the blue LED without
any load connecte
d.
Normal mode / Test mode (NORM / TEST)
DIP 2
The light automatically switches
'ON' and 'OFF' in relation to
brightness when someone is
present. Light can be switched
'ON' and 'OFF manually at any
time. This temporarily interrupts
the automatic sw
itching func-
tion. Irrespective of the settings
selected, light stays 'ON' for 4
hours after manually pressing
the button twice or switches
'OFF' after manually pressing the
b
utton once. Pressing the but-
ton before the 4 hours elapse
returns the Presence Control IR
Quattro to the normal operating
mode.
Semi-automatic mode (MAN) / fully automatic mode (AUTO)
Fully automatic mode: (AUTO)
Semi-automatic mode: (MAN)
The light now only switches
'OFF' automatically. Light is
switched 'ON' manually. Light
must be requested using the
button and stays 'ON' for the
time set at the potentiometer.
(pressi
ng twice switches 'ON' for
4 hours).
DIP 3
Tells the sensor how to interpret
the incoming signal. Assigning
external buttons/switches allows
you to operate the detector as a
semi-automatic unit and over-
ride it manually at
any time.
■ Operation either by button
or switch
■ Several buttons possible on
one control input
■ Only use illuminated pushbut-
ton with neutral conductor
connected
■ Cable length between sensor
and switch < 50 m
Button/switch
COM 1 + COM 2
DIP 5
Provides a constant level of
brightness. Detector measures
the prevailing level of daylight
and activates sufficient artificial
light to achieve the required le
v-
el of brightness. As daylight
changes, the switched-in artifi-
cial lighting component is ad-
justed accordingly. In addition to
the daylight component, artific
ial
light is also switched 'ON' and
'OFF' in relation to whether or
not persons are present.
Constant light 'ON'/'OFF'
DIM
