STEINEL IR Quattro COM 1 AP User Manual

- 23 -
Technical Specifications
Dimensions (H x W x D): 120 x 120 x 76 mm
Power supply: 230 – 240 V, 50 Hz / 60 Hz
Capacity, switching output 1: 230 V relay
(COM 1/COM 2) resistive load of 2000 W max. (cos φ = 1)
1000 VA max. (cos φ = 0.5)
El
ectronic ballast: Max. 'ON' current 800 A/200 μs
(COM 1/COM 1 AP/COM 2/DIM) 30 x (1 x 18 W), 25 x (2 x 18 W)
25 x (1 x 36 W), 15 x (2 x 36 W)
20 x (1 x 58 W), 10 x (2 x 58 W)
Pay attention to specific 'ON' currents of electronic ballasts!
A relay or contactor must be provided on line side for higher
switching capacities.
Capacity
, switching output 2: Presence
(COM 2 only) max. of 230 W/230 V
1A max., (cos φ = 1) for HV AC (heating/ventilation/air conditioning)
Square detection zones: IR Quattro IR Quattro HD
Presence: max. of 4 x 4 m (16 sq.m.) max.
of 8 x 8 m (64 sq.m.)
Radially: max. of 5 x 5 m (25 sq.m.) max. of 8 x 8 m (64 sq.m.)
Tangentially: max. of 7 x 7 m (49 sq.m.) max. of 20 x 20 m (400 sq.m.):
Light-le
vel setting: 10 – 1000 lux, ∞ / daylight /
DIM 100 – 1000 lux control threshold
Switching output 1: 30 sec. – 30 min., pulse mode (approx. 2 sec.),
Time setting IQ mode (automatic adjustment to the usage profile)
Switching output 2: COM2 only, for HVAC
Time setting 0 sec. – 10 min. switch-'ON' delay
1 min. – 2 hrs. stay-'ON' time
Automatic room surveillance
DIM: 30 sec. – 30 min.,
Time setting IQ mode (automatic adjustment
to the usage profile)
Control output: 1 – 10 V / max. of 50 electronic ballasts, max. of 100 mA
Installation height: 2.5 m – 8 m (IR Quattro)
(mounted to ceiling) 2.5 m – 10
m (IR Quattro HD)
Installation site: indoors
Sensors: 13 detection levels, 1760 switching zones (IR Quattro)
13 detection levels, 4800 switching zones (IR Quattro HD)
IP rating: IP 20
Protection class: II
Tem
perature range: 0° C to +40° C
