21
Table 3-1 Activation and Mode Selector Switch Functions
Switch Marking Use Remarks
Position
1 OFF OFF The DBAL-I
2
will not operate
2 A/L LOW IR POINT is activated Used for bore sighting and
(AIM LO) when the Remote Cable training
Switch or Integrated
Momentary Activation switch
is depressed.
3 D/L LOW IR POINT & LOW IR ILLUM Primarily used to boresight the
(DUAL LO) are activated when the Remote laser, in low light conditions,
Cable Switch or Integrated and for training.
Momentary Activation switch
is depressed.
4 A/H HIGH IR POINT is activated Used for pointing / aiming,
(AIM HI) when the Remote Cable at long ranges. DO NOT use for
Switchor Integrated Momentary bore sighting the weapon.
Activation switch is depressed.
5 L/H LOW IR POINT & HIGH IR ILLUM are
(DUAL LO/HI) activated when the Remote Cable
Switch or Integrated Momentary
Activation switch is depressed.
6 H/H HIGH IR POINT & HIGH IR ILLUM are
(DUAL HI/HI) activated when the Remote Cable
Switch or Integrated Momentary
Activation switch is depressed.
Illuminates the target area and
provides an aiming point to
accurately engage the target.
For pointing /aiming indoors
and outdoors at close range.
Illuminates the target area and
provides an aiming point to
accurately engage the target.
For pointing /aiming indoors
and outdoors at close range.
