Table 3-4 Factory Neutral Preset
Adjuster Instruction
Adjuster Guard marked U/D First, turn CW to end of travel. DO NOT
for the IR POINT force past mechanical stop. Next,
turn CCW 1
1
/4 turns. Finally, turn CW to
Adjuster Guard marked R/L for the align the dot on the adjuster with the
IR POINT dot on the adjuster guard.
3.6 DBAL-I
2
MOUNTING CONFIGURATIONS AND WEAPON OFFSETS
NOTE
Offsets have been calculated using a specific barrel length, bullet weight, and
rail adaptor. Offsets for differing combinations of equipment will require some
adjustment.
Offsets have been calculated but have not been verified by live fire on a
specific weapon. Always validate the offsets based on the specific weapon
platform and cartridge.
Table 3-5 includes weapon type, mounting configurations and offsets used
in conjunction with DBAL-I
2
. The table includes the 10-Meter Laser Borelight
Offsets as well as standard M16A2/M16A4 25-Meter Zeroing Target offsets.
