Steiner DBAL-I2 User Manual

Table 3-5 DBAL-I
2
Mounting Configurations and Weapon Offsets
Weapon Mount Range 10m Boresight Target 25m Target Zero Offset
Offset Squares to Strike Point
M4 / M16A4 Top Rail 300m IR ILLUM 2.1R / 2.9U IR ILLUM 2.1L / 0.0
IR POINT 1.9R / 3.0U IR POINT 1.9L / 0.0
M4 / M16A4 Left Rail 300m IR ILLUM 5.0L / 1.2U IR ILLUM 5.0R / 2.0U
IR POINT 5.1L / 1.1U IR POINT 4.6R / 1.8U
M4 / M16A4 Right Rail 300m IR ILLUM 4.4R / 3.6D IR ILLUM 5.0L / 7.0U
IR POINT 4.5R / 3.3D IR POINT 4.6L / 6.5U
M4 / M16 w / M203 Top Rail 300m IR ILLUM 2.2R / 3.7U IR ILLUM 2.1L / 0.0
IR POINT 2.0R / 3.9U IR POINT 1.9L / 0.0
M4 / M16 w / M203 Left Rail 300m IR ILLUM 4.3L / 0.8U IR ILLUM 4.8R / 3.0U
IR POINT 4.5L / 0.7U IR POINT 4.5L / 2.8U
M4 / M16 w / M203 Right Rail 300m IR ILLUM 4.7R / 2.8D IR ILLUM 5.0R / 7.0U
IR POINT 4.8R / 2.4D IR POINT 4.6R / 6.5U
M249 Short Barrel Top Rail 400m IR ILLUM 1.2L / 6.0U IR ILLUM 9.0R / 13.0U
IR POINT 8.5L / 2.2D IR POINT 8.3R / 12.0U
M249 Short Barrel Left Rail 400m IR ILLUM 8.4L / 2.4D IR ILLUM 2.1R / 4.4U
IR POINT 1.9R / 5.0U IR POINT 1.9R / 5.0U
45
