Table 3-5 DBAL-I
2
Mounting Configurations and Weapon Offsets, continued
Weapon Mount Range 10m Boresight Target 25m Target Zero Offset
Offset Squares to Strike Point
M249 Short Barrel Right Rail 400m IR ILLUM 4.3R / 7.5D IR ILLUM 2.1R / 4.4U
IR POINT 4.3R / 7.0D IR POINT 1.9R / 5.0U
M249 Std. Barrel Top Rail 400m IR ILLUM 4.8R / 5.5U IR ILLUM 2.1L / 2.1U
IR POINT 4.4R / 5.7U IR POINT 1.9L / 1.0U
M249 Std. Barrel Left Rail 400m IR ILLUM 4.4L / 1.8D IR ILLUM 6.7R / 9.7U
IR POINT 4.9L / 1.7D IR POINT 6.2R / 9.0U
M249 Std. Barrel Right Rail 400m IR ILLUM 5.7R / 7.4D IR ILLUM 6.7L / 13.9U
IR POINT 6.2R / 6.8D IR POINT 6.2L / 12.8U
M240B Top Rail 500m IR ILLUM 2.0R / 3.8U IR ILLUM 2.1L / 5.1U
IR POINT 1.8R / 4.2U IR POINT 1.9L / 4.7U
M240B Left Rail 500m IR ILLUM 6.0L / 3.5D IR ILLUM 6.3R / 14.6U
IR POINT 6.0L / 3.2D IR POINT 6.3R / 13.5U
M240B Right Rail 500m IR ILLUM 6.0R / 7.8D IR ILLUM 6.8L / 16.8U
IR POINT 6.4R / 7.2D IR POINT 6.3L / 15.5U
46
