DECSRIPTION
K
+42Vac Output remote control
L
+42Vac Output remote control
M
0Vac Output remote control
REMOTE CONTROL
N
0Vac Output remote control
GND G
Chassis common
A
Data Reception Serial Gate
B
Common Communication Serial Gate
C
Data Transmissions Serial Gate
D
Data Transmissions Serial Gate Speed Motor
E
Data Reception Serial Gate Speed Motor
H
Positive connection Welding Voltage
I
Negative connection Welding Voltage
TYPE CONNECTION PIN DECSRIPTION
EARTH CLAMP A
NEGATIVE
ELECTRODE B
POSITIVE
MMA
POSSIBLE REMOTE C
PIN
TYPE CONNECTION PIN DECSRIPTION
TIG TORCH A
NEGATIVE
TIG
LIFT
EARTH CLAMP B
POSITIVE
