MAINTENANCE MANUAL
STEMME TSA-M
MAINTENANCE MANUAL
STEMME TSA-M
06-10-00
Page 01
AIRCRAFT DIMENSIONS AND AREAS
1. General
A. The wing and tail spans are measured parallel to the respective reverence level.
B. Refer to Figure 1 for an illustration of aircraft dimensions.
2. Dimensions and Areas
Aircraft Overall:
Wing Span 18.00 m 59.06 ft
Overall Length 8.52 m 27.95 ft
Heigth max. 2.45 m 08.04 ft
Wing:
Wing Profile DU
2 2
Wing Area 17.42 m 187.5 ft
Dihedral Angle 2.0° ±0.12°
Mounting Angle 0.73° ±0.15°
Chord (at root rib) 1.23 m 4.04 ft
2
Max. Load 48.79 kg/m 10
Ailerons (both):
2 2
Area 1.24 m 13.34 ft
Up Travel (outboard) ( - ) 21°
Down Travel (outboard) (+) 10.5°
Neutral Position 0° ±2°
Up Travel (inboard) ( - ) 10.5°
Down Travel (inboard) (+) 5.3°
Flaps (both):
2 2
Area 1.57 m 16.9 ft
Flap Setting (Ground, LH, RH):
Cruise - 8.5°
Neutral +5.0° ±1°
Takeoff / Landing I +18.5°
Landing II +25°
2
lbs/ft
Nov 18/11
EFFECTIVITY
Model S6, 001 - 012
